1: Installation method of supporting dynamometer:

1)傳感器內置式:將4-M6螺絲穿入固定塊4-中6.2孔中，在螺紋方向各套入1個墊圈，并與側力計安裝板上4-M6螺紋旋緊，測力計安裝板上，測力計安裝孔分為兩組，分別為30x145. 40x90。用戶可根據自己的需要確定。

1) Built in sensor: insert 4-m6 screw into 6.2 hole in 4-middle of fixed block, insert a washer in thread direction, and screw it with 4-m6 thread on side force meter mounting plate. On dynamometer mounting plate, dynamometer mounting hole is divided into two groups, 30x145.40x90. Users can determine according to their own needs.

2)傳感器外置式:將2-M8螺絲穿入固定塊2-中8.5孔中，并與連接桿上2-M8螺絲旋緊。將M12螺母穿入連接桿通孔內并與傳感器旋緊即可，操作系統可安裝在外置式側力計安裝板上。

2) Sensor external type: insert the 2-m8 screw into the 8.5 hole in the fixed block 2 - and tighten it with the 2-m8 screw on the connecting rod. The operating system can be installed on the mounting plate of external lateral force meter.

扭剪型手動扳手制造廠家|扭剪型手動扳手維修電話,2：操作面板使用方法：

Manual wrench manufacturer | maintenance telephone number of twist shear type hand wrench, 2: operation panel usage:

l)電源開關:當按下按鈕時，接通電源，再次按下，電源斷開。

l) Power switch: when the button is pressed, turn on the power supply, press it again, and the power supply will be disconnected.

2)速度操作:由于被測物體及用戶要求的不同，當調整調速器旋鈕時，載體的運動速度為60-300m/min.

2) Speed operation: due to the different requirements of the tested objects and users, when the governor knob is adjusted, the motion speed of the carrier is 60-300m / min

3：功能操作:

3: Function operation:

手動/自動，當將旋鈕旋手動時，如使載體運動，則需按住升或降(DOWN)鍵，斷開則運動停止。當旋鈕旋自動時，如使載體運動則直接按升或降(DOWN)鍵。

Manual / automatic: when the knob is turned to manual, if the carrier moves, press and hold the up or down key, and the movement will stop if it is disconnected. When the knob is turned to automatic, if the carrier moves, press the up or down key directly.

4：測力計高度調整:

4: Height adjustment of dynamometer:

SHAEV雙柱立式機臺固定塊兩側為M8鎖緊鏢釘，將M8鎖緊鏢釘松開，將固定塊向上或向下移動到所需要的高度后，將M8螺釘鎖緊。

Both sides of the fixed block of shaev double column vertical machine are M8 locking dart nails. First, loosen the M8 locking dart nail, and then lock the M8 screw after moving the fixed block up or down to the required height.

扭剪型手動扳手制造廠家|扭剪型手動扳手維修電話, 5：行程調整:

Manual wrench manufacturer | maintenance telephone number of twist shear type hand wrench, 5: stroke adjustment:

導柱上十字槽螺釘為大行程的1，限位套為用戶測量所需行程調節套。計數器使用方祛:計數器上方為數字顯示屏、記錄試驗次數，下方為預置按鈕(左1一4)，右1為倍率按鈕(ix. 10X, ioox)如:用戶對某一產品進行連續測試，側試次數為5倍率為lox，則測試架往復10次顯示屏顯示為1，運行50次后自動停止，如需再次測試，按停止按鈕即可。

The cross groove screw on the guide post is 1 of the large stroke, and the limit sleeve is the stroke adjusting sleeve required by the user for measurement. How to use the counter: the top of the counter is a digital display screen to record the number of tests, and the bottom is the preset button (1-4 on the left), and 1 on the right is the multiple button (IX. 10x, ioox). For example, if the user continuously tests a certain product and the side test times are 5 and the ratio is LOX, the test rack will repeat 10 times, and the display screen will display 1, and it will stop automatically after running 50 times. If you need to test again, press the stop button.
