(1) According to the connection form, high-strength bolts are usually divided into friction connection, tension connection and pressure bearing connection. Among them, friction connection is the basic connection form widely used at present.

(2)高強度螺栓連接處的摩擦面的處理方法通常有噴砂(丸)法、酸洗法、砂輪打磨法和鋼絲刷人工除銹法等。可根據設計抗滑移系數的要求選擇處理工藝，抗滑移系數一定滿足設計要求。

(2) The treatment methods of friction surface at the joint of high-strength bolts usually include sand blasting (shot), acid pickling, grinding wheel grinding and manual rust removal with steel wire brush. The treatment process can be selected according to the requirements of the design anti slip coefficient, and the anti slip coefficient must meet the design requirements.

(3)經表面處理后的高強度螺栓連接摩擦面應符合以下規定：

(3) The friction surface of high-strength bolt connection after surface treatment shall comply with the following provisions:

1)連接摩擦面保持干燥、清潔，不應有飛邊、毛刺、焊接飛濺物、焊疤、氧化鐵皮、污垢等；

1) The connecting friction surface shall be dry and clean without flash, burr, welding spatter, welding scar, iron oxide scale, dirt, etc;

2)經處理后的摩擦面采取保護措施，不得在摩擦面上作標記；

2) Protective measures shall be taken for the treated friction surface, and no marks shall be made on the friction surface;

3)若摩擦面采用生銹處理方法時，安裝前應以細鋼絲刷垂直于構件受力方向刷除摩擦面上的浮銹。

3) If the friction surface is treated with rust, the floating rust on the friction surface shall be brushed with a fine steel wire brush perpendicular to the stress direction of the member before installation.

(4)高強度大六角頭螺栓連接副由一個螺栓、一個螺母和兩個墊圈組成，扭剪型高強度螺栓連接副由一個螺栓、一個螺母和l一個墊圈組成。

(4) The high-strength large hexagon head bolt connection pair is composed of a bolt, a nut and two washers, and the torsion shear high-strength bolt connection pair is composed of a bolt, a nut and l a washer.

(5)安裝環境氣溫不宜低于-1O"C。當摩擦面潮濕或暴露于雨雪中時，停止作業。

(5) The installation ambient temperature should not be lower than - 1o "C. when the friction surface is wet or exposed to rain and snow, stop the operation.

(6)高強度螺栓安裝時應先使用安裝螺栓和沖釘。安裝螺栓和沖釘?shù)臄?shù)量要保證能

(6) During the installation of high-strength bolts, installation bolts and punch nails shall be used first. The number of installation bolts and punch nails shall ensure that

承受構件的自重和連接校正時外力的作用，規定每個節點安裝的少個數是為了防止連接后構件位置偏移，同時限制沖釘用量。高強度螺栓不得兼做安裝螺栓。

Bearing the self weight of the member and the external force during connection correction, it is specified that the minimum number of installation at each node is to prevent the position deviation of the member after connection and limit the amount of punching nails. High strength bolts shall not be used as installation bolts.

(7)高強度螺栓現場安裝時應能自由穿人螺栓孔，不得強行穿入。若螺栓不能自由穿人時，可采用餃刀或鏗刀修整螺栓孔，不得采用氣割擴孔，擴孔數量應征得設計同意，修整后或擴孔后的孔徑不應超過1.2倍螺栓直徑。

(7) High strength bolts shall be able to penetrate the bolt hole freely during on-site installation and shall not be forced into. If the bolt cannot penetrate freely, dumpling knife or Keng knife can be used to trim the bolt hole, and gas cutting reaming shall not be used. The number of reaming shall be approved by the design, and the hole diameter after trimming or reaming shall not exceed 1.2 times the bolt diameter.

(8)高強度螺栓超擰應更換，并廢棄換下來的螺栓，不得重復使用。嚴禁用火焰或電焊切割高強度螺栓梅花頭。

(8) High strength bolts shall be replaced in case of over tightening, and the replaced bolts shall be discarded and shall not be reused. It is strictly prohibited to cut the plum blossom head of high strength bolts with flame or electric welding.

(9)高強度螺栓長度應以螺栓連接副終擰后外露2-3扣絲為標準計算，應在構件安裝精度調整后進行擰緊。扭剪型高強度螺栓終擰檢查，以目測尾部梅花頭擰斷為合格。

(9) The length of high-strength bolt shall be calculated based on the exposed 2-3 threads after the final tightening of bolt connection pair, and shall be tightened after the adjustment of component installation accuracy. The final tightening inspection of torsion shear high-strength bolt shall be qualified if the plum blossom head at the tail is broken by visual inspection.

(10)高強度大六角頭螺栓連接副施擰可采用扭炬法或轉角法。同一接頭中，高強度螺栓連接副的初擰、復擰、終擰應在24h內完成。高強度螺栓連接副初擰、復擰和終擰原則上應以接頭剛度較大的部位向約束較小的方向、螺栓群向四周的順序進行。

(10) The torque torch method or angle method can be used for the tightening of high-strength large hexagon head bolt connection pair. In the same joint, the initial tightening, re tightening and final tightening of high-strength bolt connection pair shall be completed within 24h. In principle, the initial tightening, re tightening and final tightening of high-strength bolt connection pair shall be carried out in the order of the part with large joint stiffness to the direction with less restraint and the center of bolt group to the surrounding.

(11)高強度螺栓和焊接并用的連接節點，當設計文件無規定時，宜按先螺栓緊固后焊接的施工順序。

(11) For the connection joints with high-strength bolts and welding, when there are no provisions in the design documents, the construction sequence of bolt fastening before welding should be followed.
